> >>GATE ASTER V2 SE EXPERT + Quantum trigger - Wired Front
GATE ASTER V2 SE EXPERT + Quantum trigger - Wired Front - View larger

GATE ASTER V2 SE EXPERT + Quantum trigger - Wired Front

AST2S-EMF

New product

Trigger included in one of available colors. No choice of color or type !

More details

Out of stock - No date of restock

Moyenne des votes pour ce produit
0 / 5
Moyenne : 0 / 5
Basée sur 0 avis clients.

62,42 € tax excl.

Si vous souhaitez enregistrer votre configuration, vous devez d'abord vous connecter.

Connexion

More info

ASTER V2 SE raises the price-performance ratio by including a Quantum Trigger in the set and new functions programmable via trigger. Now, out-of-the-box, you can set sensitivity from ludicrous touch through hair to full movement. Improved programming via trigger gives you new settings such as automatic Pre-Cocking (LOW, MID, HIGH), trigger sensitivity adjustment, Active Brake settings with top-class adaptive mode and the new SAFE-SEMI-BINARY selector mode. Calibration, DTC codes—all available just via trigger and selector movement. Additionally, you get the new noise-resistant trigger detection algorithm. ASTER's smart fuse protects your AEG’s battery, motor, and the controller, even in the case of reverse battery connection. This feature, along with the optical sensors, makes ASTER V2 SE one of the most durable ETUs on the market. ASTER V2 SE is not just a regular ETU/EFCS mosfet. It is a complex system that turns your AEG into future-proof advanced training equipment.

ASTER is future-proof, thanks to compatibility with USB-Link and Blu-Link. You can update your firmware and get new options, connect additional accessories, check telemetry.

  • ‎
  • What is an ETU? It is an Electronic Trigger Unit replacing trigger contacts and the cut-off lever, which takes control of your AEG.
  • Why ASTER's programming via trigger is user-friendly?

‎

  • you do not need to rush
  • you can navigate the menu very quickly and efficiently or slowly and calmly
  • the colors of the led lights are only a help – you can rely on the vibration of the motor
  • in case of any problems, you can use the very popular USB-Link or Blu-Link and use the GCS App

What is the self-learning automatic pre-cocking?

  • thanks to Pre-cocking, you gain trigger reaction similar to real life
  • it will automatically set piston position
  • it is easy-to-use, just set one of the 3 modes: LOW, MID or HIGH
  • it automatically adapts to the battery voltage and rate of fire
  • ASTER gives you great flexibility and is future-proof. Today you can program the most important functions with the trigger, and tomorrow you can borrow a USB-Link or Blu-Link from a friend to configure advanced functions, perform a firmware update, run diagnostics or use the GCS app on a smartwatch
  • Hair-trigger – up to 60 sensitivity in the first millimeter of trigger movement
  • Top-notch automatic pre-cocking
  • ASTER is resistant to reverse polarity
  • You can update its firmware via the Internet
  • ASTER is a part of the GATE Ecosystem
  • Lowest in the market current consumption. Deep sleep mode with only 0.29 mA current consumption prevents battery discharge
  • Built-in voltage boost converter allows for trouble-free operation with weaker batteries and increases the switching efficiency
  • 3.75 V ready – it operates at very low voltage (even 1.2 V during the shot), which is important in high-tuned AEGs, where the voltage under load drops significantly
  • Sensor that supports Infinite Torque-up, DSG, SSG, 19-tooth and standard gears
  • The possibility of using a mechanical trigger lock
  • Compatibility with brushless motors

Data sheet

GearboxV2
Battery ConnectorDEAN (T-Plug)

GATE

GATE

The GATE mission statement:  ‘To give every airsoft player a more exciting experience and to provide them with access to the most up-to-date technology for their airsoft games’ is well taken to heart by the company’ staff. Every product at GATE goes through advanced technology process. Prototypes are designed using modern software and sophisticated hardware. We rely on reliability and miniaturization.

Beginning in 2014, each product, prior to its introduction to the market, is tested by 50 independent beta-testers. Thanks to our long-term research, meticulous tests and our experience, our products are reliable and can operate under most harsh conditions. All products comply with ROHS 2 and meet CE standards. Electronic circuits are being made using modern technologies. SMD 0603 components and 8 mils traces are our standard. High-density multi-layer PCBs allow large scale miniaturization. In high power circuits, we use most powerful transistors available on market: HEXFET Power MOSFETs International Rectifier, NXP N-channel logic level MOSFET in LFPAK using NextPower technology, Vishay P-channel MOSFET in PowerPAK SO-8 using TrenchFET technology. Because of an optimised output capacitance, body diode and channel structure, MOSFETs exhibit “soft-recovery” switching behaviour, resulting in lower voltage spikes, faster decays and virtually no gate glitches. Moreover, increasing switching frequency from 300KHz to 1MHz allows a 70 - 80% reduction in inductor size. MOSFETs' excellent switching performance enables such design choices with minimal loss of efficiency.

For eight years, our company has been designing and producing the most innovative AEG Control Systems and MOSFETs. We have premises located in Cracow, Poland. Our products successfully entered global markets and are being sold in more than 20 countries.  Why should you choose GATE while upgrading your gun? Thanks to our products, your skirmish becomes a more exciting experience. The variety of functions and protections our Controllers and MOSFETs give to your gun is enormous.

See all products from GATE

Questions  (1)

A partir de ewann | 2024-09-15 19:55:18

Good morning,
Is it compatible with the m4 we katana replica?

Powair6

Hello , it is compatible with Katana .

Regards,
